Product Details
Place of Origin: China
Brand Name: Hua Power
Model Number: TP-160H
Payment & Shipping Terms
Packaging Details: Carton+Pallet
Delivery Time: 30-35 working days
Payment Terms: T/T, L/C
Supply Ability: 1000pcs per month
Capacity: |
160Ah |
Rated Voltage: |
48V |
Charge Temperature: |
0~55℃ |
Discharge Temperature: |
-20~60℃ |
Cycle Life: |
>5000 (<0.5C, DOD80%) |
Rated Input/ Ouput Current: |
100A |
Charging Mode (CC-CV): |
MAX 54.75V |
Voltage At End Of Discharge: |
42V |
Factory SOC: |
30~60% |
Depth Of Discharge: |
>80% |
Product Name: |
LiFePO4 Battery Pack |
Communication Mode: |
RS485 / CAN |
Protection: |
Over-charge, Over-discharge, Over-current, Short-circuit |
Product Size: |
L*W*H=830*600*110mm (±2mm) |
Product Net Weight: |
76.37KGS |
Capacity: |
160Ah |
Rated Voltage: |
48V |
Charge Temperature: |
0~55℃ |
Discharge Temperature: |
-20~60℃ |
Cycle Life: |
>5000 (<0.5C, DOD80%) |
Rated Input/ Ouput Current: |
100A |
Charging Mode (CC-CV): |
MAX 54.75V |
Voltage At End Of Discharge: |
42V |
Factory SOC: |
30~60% |
Depth Of Discharge: |
>80% |
Product Name: |
LiFePO4 Battery Pack |
Communication Mode: |
RS485 / CAN |
Protection: |
Over-charge, Over-discharge, Over-current, Short-circuit |
Product Size: |
L*W*H=830*600*110mm (±2mm) |
Product Net Weight: |
76.37KGS |
